Description
MGT4012PB-W28 Protechnic 12VDC 0.853m³/min 30.12CFM 1207.61Pa 4.846inH2O 26000RPM 2A 24W 62.8dB(A) 40x40x28mm Ball Bearing 4 Wire Leads DC Axial Fan
Specifications
| Model Number | MGT4012PB-W28 |
|---|---|
| Noise Level | 62.8 dB(A) |
| Fan Type | DC |
| Voltage Rating | 12 VDC |
| Air Flow CMM | 0.853 m³/min |
| Air Flow | 30.12 CFM |
| Static Pressure Pa | 1207.61 Pa |
| Static Pressure mmAq | 123.1 mmAq |
| Static Pressure | 4.846 in H2O |
| Fan Speed | 26000 RPM |
| Current Rating | 2 A |
| Power Rating | 24 W |
| Manufacturer | Protechnic Electric |
| Dimensions | 40x40x28 mm |
| Weight | 45 g |
| Bearing Type | Ball Bearing |
| Material Blade | Plastic |
| Material Frame | Plastic |
| Lifetime @ Temp | 40000 Hrs @ 60°C |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Storage Temperature | -40℃～70℃(5%～95% RH) |
| Approval Agency | CE, TUV, UL |
| Termination | 4 Wire Leads |
| Category | Axial Fan |
| Features | Pulse width modulation,automatic restart,locked current protection(PWM) |
| series | 40*40*28mm seriesF |
| Product PDF | MGT4012PB-W28-Protechnic.pdf |
