Description
BD24B3 Comair Rotron 19030621A 121x121x31mm 24VDC 0.48A 11.5W 3040RPM 24.3CFM 42.1m³/h 51.2dB(A) Ball 0.87inH2O 217Pa 2 Wire Leads Blower fan
Specifications
| Model Number | BD24B3 |
|---|---|
| Air Flow | 24.3 CFM |
| Weight | 280 g |
| Manufacturer | Comair Rotron |
| Series | Biscuit DC |
| Dimensions | 121x121x31 mm |
| Voltage Rating | 24 VDC |
| Fan Type | DC |
| Operating Voltage | 12 – 28VDC |
| Current Rating | 0.48 A |
| Power Rating | 11.5 W |
| Fan Speed | 3040 RPM |
| Air Flow (m3) | 42.1 m³/h |
| Bearing Type | Ball Bearing |
| Part Number | 19030621A |
| Noise Level | 51.2 dB(A) |
| Static Pressure | 0.87 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 85°C |
| Approval Agency | CE, cUL, UL |
| Lifetime @ Temp | 52000 Hrs @ 70°C |
| Propeller | Plastic, Black, UL94V-0 |
| Venturi | Plastic, Black, UL94V-0 |
| Termination | 2 Wire Leads |
| Category | Blower |
| Static Pressure Pa | 217 Pa |
| Product PDF | BD24B3-Comair-Rotron.pdf |
