Description
W2E250-HL06-17 ebmpapst 280x80mm 230VAC 135W 1865m³/h 2550RPM 70dB(A) IP20 Leads AC axial fan
Specifications
| Model Number | W2E250-HL06-17 |
|---|---|
| Manufacturer | ebm-papst |
| Fan Type | AC |
| Bearing Type | Ball Bearing |
| Dimensions | 280×80 mm |
| Voltage Rating | 230 VAC |
| Power Rating | 135 W |
| Fan Speed | 2550 RPM |
| Noise Level | 70 dB(A) |
| Termination | Leads |
| Category | Axial |
| IP Rating | IP20 |
| Series | W2E250 |
| RoHS Status | ROHS3 Compliant |
| Air Flow CMH | 1865 m³/h |
| Product PDF | W2E250-HL06-17-ebmpapst.pdf |
