Description
SPDD12K1 Comair Rotron 17000301A 161x161x51mm 12VDC 6.30A 75.3W 4000RPM 100.5CFM 171.0m³/h 67.2dB(A) Ball 2.05inH2O 510Pa 2 Wire Leads Blower fan
Specifications
| Model Number | SPDD12K1 |
|---|---|
| Air Flow | 100.5 CFM |
| Weight | 950 g |
| Manufacturer | Comair Rotron |
| Series | Spinnaker DC |
| Dimensions | 161x161x51 mm |
| Voltage Rating | 12 VDC |
| Fan Type | DC |
| Operating Voltage | 6 – 14VDC |
| Current Rating | 6.30 A |
| Power Rating | 75.3 W |
| Fan Speed | 4000 RPM |
| Air Flow (m3) | 171.0 m³/h |
| Bearing Type | Ball Bearing |
| Part Number | 17000301A |
| Noise Level | 67.2 dB(A) |
| Static Pressure | 2.05 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 85°C |
| Approval Agency | CE, cUL, UL |
| Lifetime @ Temp | 45000 Hrs @ 70°C |
| Propeller | Plastic, Black, UL94V-0 |
| Venturi | Plastic Housing and Metal Backplate |
| Termination | 2 Wire Leads |
| Category | Blower |
| Static Pressure Pa | 510 Pa |
| Product PDF | SPDD12K1-Comair-Rotron.pdf |
