Description
PQ12C4 Comair Rotron 19031086A 172x51mm 12VDC 1.26A 15.1W 2800RPM 194CFM 334.8m³/h 50.1dB(A) Ball 0.56inH2O 140Pa 2 Terminals Axial DC fan
Specifications
| Model Number | PQ12C4 |
|---|---|
| Air Flow | 194 CFM |
| Weight | 840 g |
| Manufacturer | Comair Rotron |
| Series | Patriot DC |
| Dimensions | 172×51 mm |
| Voltage Rating | 12 VDC |
| Fan Type | DC |
| Operating Voltage | 6 – 14VDC |
| Current Rating | 1.26 A |
| Power Rating | 15.1 W |
| Fan Speed | 2800 RPM |
| Air Flow (m3) | 334.8 m³/h |
| Bearing Type | Ball Bearing |
| Part Number | 19031086A |
| Noise Level | 50.1 dB(A) |
| Static Pressure | 0.56 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 85°C |
| Approval Agency | CE, cUL, UL |
| Lifetime @ Temp | 58000 Hrs @ 70°C |
| Propeller | Plastic, Black, UL 94V-0 |
| Venturi | Die Cast Aluminum |
| Termination | 2 Terminals |
| Category | Axial DC |
| Static Pressure Pa | 140 Pa |
| Product PDF | PQ12C4-Comair-Rotron.pdf |
