Description
MTD24Z3 Comair Rotron 17000019A 172x150x55mm 24VDC 2.20A 52.8W 4200RPM 363CFM 616.7m³/h 61.7dB(A) Ball 1.21inH2O 300Pa 2 Wire Leads Axial DC fan
Specifications
| Model Number | MTD24Z3 |
|---|---|
| Air Flow | 363 CFM |
| Weight | 835 g |
| Manufacturer | Comair Rotron |
| Series | Maltese DC |
| Dimensions | 172x150x55 mm |
| Voltage Rating | 24 VDC |
| Fan Type | DC |
| Operating Voltage | 12 – 28VDC |
| Current Rating | 2.20 A |
| Power Rating | 52.8 W |
| Fan Speed | 4200 RPM |
| Air Flow (m3) | 616.7 m³/h |
| Bearing Type | Ball Bearing |
| Part Number | 17000019A |
| Noise Level | 61.7 dB(A) |
| Static Pressure | 1.21 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 85°C |
| Approval Agency | CE, cUL, UL |
| Lifetime @ Temp | 76000 Hrs @ 40°C |
| Propeller | Plastic, Black, UL 94V-0 |
| Venturi | Die Cast Aluminum |
| Termination | 2 Wire Leads |
| Category | Axial DC |
| Static Pressure Pa | 300 Pa |
| Product PDF | MTD24Z3-Comair-Rotron.pdf |
