Description
MGA9212XR-O25 Protechnic 12VDC 1.474m³/min 52.03CFM 43.26Pa 0.174inH2O 2900RPM 0.32A 3.84W 33.5dB(A) 92x92x25mm Rifle Bearing 2 Wire Leads DC Axial Fan
Specifications
| Model Number | MGA9212XR-O25 |
|---|---|
| Manufacturer | Protechnic Electric |
| Dimensions | 92x92x25 mm |
| Actual Power | 1.92 W |
| Fan Type | DC |
| Voltage Rating | 12 VDC |
| Air Flow CMM | 1.474 m³/min |
| Air Flow | 52.03 CFM |
| Static Pressure Pa | 43.26 Pa |
| Static Pressure mmAq | 4.41 mmAq |
| Static Pressure | 0.174 in H2O |
| Fan Speed | 2900 RPM |
| Current Rating | 0.32 A |
| Actual Current | 0.16 A |
| Power Rating | 3.84 W |
| Weight | 93 g |
| Noise Level | 33.5 dB(A) |
| Bearing Type | Rifle Bearing |
| Material Blade | Plastic |
| Material Frame | Plastic |
| Lifetime @ Temp | 40000 Hrs @ 60°C |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Storage Temperature | -40℃～70℃(5%～95% RH) |
| Approval Agency | CE, TUV, UL |
| Termination | 2 Wire Leads |
| Category | Axial Fan |
| Features | Automatic restart,locked current protection |
| series | 92*92*25mm seriesI |
| Shipping Weight | 0.25 kg |
| Product PDF | MGA9212XR-O25-Protechnic.pdf |
