Description
MGA6012ZB-O25 Protechnic 12VDC 0.889m³/min 31.38CFM 102.71Pa 0.412inH2O 6000RPM 0.31A 3.72W 39.8dB(A) 60x60x25mm Ball Bearing 2 Wire Leads DC Axial Fan
Specifications
| Model Number | MGA6012ZB-O25 |
|---|---|
| Manufacturer | Protechnic Electric |
| Fan Type | DC |
| Voltage Rating | 12 VDC |
| Air Flow CMM | 0.889 m³/min |
| Air Flow | 31.38 CFM |
| Static Pressure Pa | 102.71 Pa |
| Static Pressure mmAq | 10.47 mmAq |
| Static Pressure | 0.412 in H2O |
| Fan Speed | 6000 RPM |
| Current Rating | 0.31 A |
| Actual Current | 0.18 A |
| Power Rating | 3.72 W |
| Actual Power | 2.16 W |
| Noise Level | 39.8 dB(A) |
| Weight | 59 g |
| Dimensions | 60x60x25 mm |
| Bearing Type | Ball Bearing |
| Material Blade | Plastic |
| Material Frame | Plastic |
| Lifetime @ Temp | 40000 Hrs @ 60°C |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Storage Temperature | -40℃～70℃(5%～95% RH) |
| Approval Agency | CE, TUV, UL |
| Termination | 2 Wire Leads |
| Category | Axial Fan |
| Features | Automatic restart,locked current protection |
| series | 60*60*25mm seriesA |
| Shipping Weight | 0.5 kg |
| Product PDF | MGA6012ZB-O25-Protechnic.pdf |
