Description
DD692112B1A Comair Rotron 17000276A 175x53mm 12VDC 2.01A 24.1W 2950RPM 227CFM 385.8m³/h 65.1dB(A) Ball 1.31inH2O 326Pa 3 Wire Leads Impeller fan
Specifications
| Model Number | DD692112B1A |
|---|---|
| Air Flow | 227 CFM |
| Weight | 860 g |
| Manufacturer | Comair Rotron |
| Series | DD6921 |
| Dimensions | 175×53 mm |
| Voltage Rating | 12 VDC |
| Fan Type | DC |
| Operating Voltage | 7 – 15VDC |
| Current Rating | 2.01 A |
| Power Rating | 24.1 W |
| Fan Speed | 2950 RPM |
| Air Flow (m3) | 385.8 m³/h |
| Bearing Type | Ball Bearing |
| Part Number | 17000276A |
| Noise Level | 65.1 dB(A) |
| Static Pressure | 1.31 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 85°C |
| Approval Agency | CE, cUL, UL |
| Lifetime @ Temp | 55000 Hrs @ 40°C |
| Propeller | Metal, Plated |
| Venturi | Die Cast Aluminum |
| Termination | 3 Wire Leads |
| Category | Impeller |
| Static Pressure Pa | 326 Pa |
| Product PDF | DD692112B1A-Comair-Rotron.pdf |
