Description
CR2206DC48V Comair Rotron 17002080A 222x60mm 48VDC 1.70A 60W 4000RPM 625.7CFM 1063.7m³/h 72dB(A) Ball 1.29inH2O 322Pa 2 Wire Leads Axial DC fan
Specifications
| Model Number | CR2206DC48V |
|---|---|
| Air Flow | 625.7 CFM |
| Weight | 1200 g |
| Manufacturer | Comair Rotron |
| Series | CR2206 DC |
| Dimensions | 222×60 mm |
| Voltage Rating | 48 VDC |
| Fan Type | DC |
| Operating Voltage | 43.2-52.8VDC |
| Current Rating | 1.70 A |
| Power Rating | 60 W |
| Fan Speed | 4000 RPM |
| Air Flow (m3) | 1063.7 m³/h |
| Bearing Type | Ball Bearing |
| Part Number | 17002080A |
| Noise Level | 72 dB(A) |
| Static Pressure | 1.29 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 85°C |
| Approval Agency | CE, UL |
| Lifetime @ Temp | 50000 Hrs @ 40°C |
| Propeller | Die Cast magnesium alloy, ED coating and powder coating |
| Venturi | Die Cast magnesium alloy, ED coating and powder coating |
| Termination | 2 Wire Leads |
| Category | Axial DC |
| Static Pressure Pa | 322 Pa |
| Product PDF | CR2206DC48V-Comair-Rotron.pdf |
