Description
CLE3T5 Comair Rotron 19039203A 254×110mm 220/230VAC 0.44A|0.57A 98W|135W 2650RPM|2800RPM 878CFM|950CFM 1492/1615m³/h 62.1dB(A)|63.3dB(A) Ball 0.50inH2O|0.57inH2O 125Pa|142Pa 2 Terminals Axial AC fan
Specifications
| Model Number | CLE3T5 |
|---|---|
| Bearing Type | Ball Bearing |
| Category | Axial AC |
| Termination | 2 Terminals |
| Venturi | Aluminum, Black |
| Propeller | Plastic, Black, UL 94V-0 |
| Lifetime @ Temp | 45000 Hrs @ 60°C |
| Approval Agency | CE, cUL, UL |
| Storage Temperature | -40°C to 85°C |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Static Pressure | 0.50 in H2O, 0.57 in H2O |
| Noise Level | 62.1 dB(A), 63.3 dB(A) |
| Part Number | 19039203A |
| Air Flow (m3) | 1492/1615 m³/h |
| Air Flow | 878 CFM, 950 CFM |
| Fan Speed | 2650 RPM, 2800 RPM |
| Power Rating | 135 W, 98 W |
| Current Rating | 0.44 A, 0.57 A |
| Frequency | 50/60 Hz |
| Fan Type | AC |
| Voltage Rating | 220/230 VAC |
| Dimensions | 254×110 mm |
| Series | Caravel XL AC |
| Manufacturer | Comair Rotron |
| Weight | 2100 g |
| Static Pressure Pa | 125 Pa, 142 Pa |
| Product PDF | CLE3T5-Comair-Rotron.pdf |
