Description
BFB0524HH Delta 51x51x15mm Ball 24VDC 4.59CFM(0.130m3/min) 0.866inchH2O(22.00mmH2O) 45.0dB(A) 2.64W 6500RPM 2-wire leads blower fan
The Delta BFB0524HH DC brushless blower features a rated voltage of 24VDC with an operation range of 14.0-27.6VDC, maximum input current of 0.16A (3.84W power), 6500RPM speed, maximum air flow of 0.130m³/min (4.59CFM), maximum air pressure of 22.00mmH₂O (0.866inchH₂O), and acoustic noise ≤48dB-A. Equipped with two ball bearings, it ensures a 50,000-hour lifespan at 40℃, operating within -10℃~+70℃, and integrates locked rotor protection (preventing fire within 96 hours under locked rotor) and polarity protection. This blower is ideal for applications requiring reliable cooling in servers, industrial control systems, medical equipment, and electronic enclosures where efficient air circulation and low noise are critical.
Specifications
| Part Number | BFB0524HH |
|---|---|
| Manufacturer | Delta Electronics |
| Fan Type | DC |
| Approval Agency | CE, CSA, UL, VDE |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Features | Locked Rotor Protection |
| Series | BFB |
| Air Flow (m3) | 0.130 m3/min |
| Dimensions | 51x51x15 mm |
| Termination | 2 wire leads |
| Fan Speed | 6500 RPM |
| Power Rating | 2.64 W |
| Noise Level | 45.0 dB(A) |
| Static Pressure | 0.866 inchH2O (22.00 mmH2O) |
| Air Flow | 4.59 CFM |
| Voltage Rating | 24 VDC |
| Bearing Type | Ball Bearing |
| Weight | 0.062 lb (28.12 g) |
| Category | Blower |
| Current Rating | 0.11 A |
| Operating Voltage | 14 ~ 27.6 VDC |
| Material Frame | Plastic |
| Material Blade | Plastic |
| Lifetime @ Temp | 50000 Hrs @ 40⁰C |
| Subcategory | DC Blower |
