Description
BFB03512LA-A Delta 12VDC 35x35x10mm 1.3CFM 0.163inH2O(40.6Pa) Ball 24dB(A) 480mW 5500RPM 2 Wire Leads Locked Rotor Protection DC Fan
Specifications
| Part Number | BFB03512LA-A |
|---|---|
| Bearing Type | Ball Bearing |
| Series | BFB |
| Voltage Rating | 12 VDC |
| Dimensions | 35x35x10 mm |
| Air Flow | 1.3 CFM |
| Air Flow (m3) | 0.036 m³/min |
| Static Pressure | 0.163 in H2O (40.6 Pa) |
| Manufacturer | Delta Electronics |
| Features | Locked Rotor Protection |
| Fan Type | DC |
| Noise Level | 24 dB(A) |
| Power Rating | 480 mW |
| Fan Speed | 5500 RPM |
| Termination | 2 Wire Leads |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Approval Agency | CE, CSA, UL, VDE |
| Weight | 0.025 lb (11.34 g) |
| Product PDF | BFB03512LA-A-Delta.pdf |
