Description
W2E143-AA15-01 ebmpapst 115VAC 171.5x51mm 258.9CFM Ball 60dB(A) 26W 3300RPM 2 Terminals Tubeaxial AC Fan
The W2E143-AA15-01 AC axial compact fan by ebm-papst features a 115VAC single-phase motor (M2E052-BF), running at 2800rpm/3300rpm for 50Hz/60Hz frequencies with 24W/28W power input and 0.25A/0.23A current draw, paired with a 3μF/250VDB capacitor. Measuring 143mm in size and weighing 0.94kg, it has 5 black-coated steel blades and a die-cast aluminum wall ring, rotating counter-clockwise to direct airflow in a “V” pattern. With IP20 protection and class “B” insulation, it operates at -25°C to 70°C ambient temperature, supported by ball bearings for any mounting position. Certified by CE, UL, CSA, EAC, VDE, and UL 507, it includes a plug connection and internal thermal overload protection, achieving max airflow of 375m³/h (50Hz) and 445m³/h (60Hz) under free-air conditions.
Specifications
| Part Number | W2E143-AA15-01 |
|---|---|
| Manufacturer | ebm-papst |
| Series | W2E143 |
| Fan Type | AC |
| Voltage Rating | 115 VAC |
| Dimensions | 171.5×51 mm |
| Air Flow | 258.9 CFM |
| Air Flow (m3) | 7.25m³/min |
| Bearing Type | Ball Bearing |
| Subcategory | Tubeaxial |
| Noise Level | 60 dB(A) |
| Power Rating | 26 W |
| Fan Speed | 3300 RPM |
| Termination | 2 Terminals |
| Operating Temperature | -40 ~ 176°F (-40 ~ 80°C) |
| Approval Agency | CCC, CE, CSA, GOST, UL, VDE |
| Weight | 2.1 lbs (952.5 g) |
