Description
ST24Z3 Comair Rotron 19032556A 80x80x32mm 24VDC 0.25A 6W 4700RPM 45CFM 76.5m³/h 51.5dB(A) Ball 0.37inH2O 92Pa 2 Wire Leads Axial DC fan
Specifications
| Model Number | ST24Z3 |
|---|---|
| Air Flow (m3) | 76.5 m³/h |
| Weight | 180 g |
| Manufacturer | Comair Rotron |
| Series | Sprint DC |
| Dimensions | 80x80x32 mm |
| Voltage Rating | 24 VDC |
| Fan Type | DC |
| Operating Voltage | 12 – 28VDC |
| Current Rating | 0.25 A |
| Power Rating | 6 W |
| Fan Speed | 4700 RPM |
| Air Flow | 45 CFM |
| Part Number | 19032556A |
| Bearing Type | Ball Bearing |
| Noise Level | 51.5 dB(A) |
| Static Pressure | 0.37 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 85°C |
| Approval Agency | CE, cUL, UL |
| Lifetime @ Temp | 45000 Hrs @ 70°C |
| Propeller | Plastic, Black, UL 94V-0 |
| Venturi | Plastic, Black, UL 94V-0 |
| Termination | 2 Wire Leads |
| Category | Axial DC |
| Static Pressure Pa | 92 Pa |
| Product PDF | ST24Z3-Comair-Rotron.pdf |
