Description
EHB1548SHG-F00 Delta 48VDC 172x150x50.80mm 347.1CFM 1.492inH2O(371.6Pa) Ball 66.5dB(A) 42.24W 4900RPM 3 Wire Leads Locked Rotor Protection, Speed Sensor (Tach) DC Fan
Specifications
| Part Number | EHB1548SHG-F00 |
|---|---|
| Bearing Type | Ball Bearing |
| Series | EHB |
| Voltage Rating | 48 VDC |
| Dimensions | 172x150x50.80 mm |
| Air Flow | 347.1 CFM |
| Air Flow (m3) | 9.72 m³/min |
| Static Pressure | 1.492 in H2O (371.6 Pa) |
| Manufacturer | Delta Electronics |
| Features | Locked Rotor Protection, Speed Sensor (Tach) |
| Fan Type | DC |
| Noise Level | 66.5 dB(A) |
| Power Rating | 42.24 W |
| Fan Speed | 4900 RPM |
| Termination | 3 Wire Leads |
| Operating Temperature | -40 ~ 176°F (-40 ~ 80°C) |
| Approval Agency | CE, CSA, UL, VDE |
| Weight | 1.8 lbs (816.5 g) |
| Product PDF | EHB1548SHG-F00-Delta.pdf |
