Description
DD692748Z1E5X Comair Rotron 19043171A 175x69mm 48VDC 1.20A 52.9W 3435RPM 354CFM 601.0m³/h 71.2dB(A) Ball 1.80inH2O 448Pa Harness Impeller fan
Specifications
| Model Number | DD692748Z1E5X |
|---|---|
| Air Flow | 354 CFM |
| Weight | 1100 g |
| Manufacturer | Comair Rotron |
| Series | DD6927 |
| Dimensions | 175×69 mm |
| Voltage Rating | 48 VDC |
| Fan Type | DC |
| Operating Voltage | 24 – 72VDC |
| Current Rating | 1.20 A |
| Power Rating | 52.9 W |
| Fan Speed | 3435 RPM |
| Air Flow (m3) | 601.0 m³/h |
| Bearing Type | Ball Bearing |
| Part Number | 19043171A |
| Noise Level | 71.2 dB(A) |
| Static Pressure | 1.80 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 75°C, |
| Approval Agency | CE, UL |
| Lifetime @ Temp | 50000 Hrs @ 40°C |
| Propeller | Metal, Plated |
| Venturi | Die Cast Aluminum |
| Termination | Harness |
| Category | Impeller |
| Static Pressure Pa | 448 Pa |
| Product PDF | DD692748Z1E5X-Comair-Rotron.pdf |
