Description
CR2258DC24V Comair Rotron 17002083A 225x225x80mm 24VDC 4.20A 82W 3600RPM 713.9CFM 1213.7m³/h 71dB(A) Ball 1.24inH2O 309Pa 2 Wire Leads Axial DC fan
Specifications
| Model Number | CR2258DC24V |
|---|---|
| Air Flow | 713.9 CFM |
| Weight | 1730 g |
| Manufacturer | Comair Rotron |
| Series | CR2258 DC |
| Dimensions | 225x225x80 mm |
| Voltage Rating | 24 VDC |
| Fan Type | DC |
| Operating Voltage | 21.6-26.4VDC |
| Current Rating | 4.20 A |
| Power Rating | 82 W |
| Fan Speed | 3600 RPM |
| Air Flow (m3) | 1213.7 m³/h |
| Bearing Type | Ball Bearing |
| Part Number | 17002083A |
| Noise Level | 71 dB(A) |
| Static Pressure | 1.24 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 85°C |
| Approval Agency | CE, UL |
| Lifetime @ Temp | 50000 Hrs @ 40°C |
| Propeller | Die Cast magnesium alloy, ED coating and powder coating |
| Venturi | Die Cast magnesium alloy, ED coating and powder coating |
| Termination | 2 Wire Leads |
| Category | Axial DC |
| Static Pressure Pa | 309 Pa |
| Product PDF | CR2258DC24V-Comair-Rotron.pdf |
