Description
BFB1224EH-A Delta 120x120x32mm Ball 24VDC 54.85CFM(1.553m3/min) 3.485inchH2O(88.51mmH2O) 62.0dB(A) 26.88W 4000RPM 2wireleads fan
Specifications
| Part Number | BFB1224EH-A |
|---|---|
| Manufacturer | Delta Electronics |
| Fan Type | DC |
| Approval Agency | CE, CSA, UL, VDE |
| Operating Temperature | 14 ~ 140°F (-10 ~ 60°C) |
| Features | Locked Rotor Protection |
| Series | BFB |
| Air Flow (m3) | 1.553 m3/min |
| Dimensions | 120x120x32 mm |
| Termination | 2 wire leads |
| Fan Speed | 4000 RPM |
| Power Rating | 26.88 W |
| Noise Level | 62.0 dB(A) |
| Static Pressure | 3.485 inchH2O (88.51 mmH2O) |
| Air Flow | 54.85 CFM |
| Voltage Rating | 24 VDC |
| Bearing Type | Ball Bearing |
| Weight | 0.661 lb (299.82 g) |
| Category | Blower |
| Current Rating | 1.12 A |
| Operating Voltage | 14 ~ 27.6 VDC |
| Material Frame | Plastic |
| Lifetime @ Temp | 50000 Hrs @ 40⁰C |
| Shipping Weight | 0.5 kg |
| Product PDF | BFB1224EH-A-Delta.pdf |
