Description
BFB04512HHA-C Delta 45x45x10.3mm Ball 12VDC 3.49CFM(0.099m3/min) 0.560inchH2O(14.22mmH2O) 35.5dB(A) 1.56W 5900RPM 2wireleads fan
Specifications
| Model | BFB04512HHA-C |
|---|---|
| Manufacturer | Delta Electronics |
| Dimensions | 45x45x10.3 mm |
| Fan Type | DC |
| Approval Agency | CE, CSA, UL, VDE |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Features | Locked Rotor Protection |
| Series | BFB |
| Air Flow (m3) | 0.099 m3/min |
| Termination | 2 wire leads |
| Fan Speed | 5900 RPM |
| Power Rating | 1.56 W |
| Noise Level | 35.5 dB(A) |
| Static Pressure | 0.560 inchH2O (14.22 mmH2O) |
| Air Flow | 3.49 CFM |
| Voltage Rating | 12 VDC |
| Bearing Type | Ball Bearing |
| Weight | 0.04 lb (18.14 g) |
| Category | Blower |
| Current Rating | 0.26 A |
| Operating Voltage | 5 ~ 13.2 VDC |
| Material Frame | Plastic |
| Material Blade | Plastic |
| Lifetime @ Temp | 30000 Hrs @ 40°C |
| Subcategory | DC axial compact fan |
| Shipping Weight | 0.25 kg |
| Product PDF | BFB04512HHA-C-Delta.pdf |
