Description
AFB0405MA-AR00 Delta 40x40x10mm Ball 5VDC 5.67CFM(0.161m3/min) 0.104inH2O(2.65mmH2O) 21.5dB(A) 0.25W 5000RPM 3wireleads
Specifications
| Part Number | AFB0405MA-AR00 |
|---|---|
| Power Rating | 0.25 W |
| Approval Agency | CE, CSA, UL, VDE |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Features | Locked Rotor Sensor |
| Series | AFB |
| Air Flow (m3) | 0.161 m3/min |
| Dimensions | 40x40x10 mm |
| Termination | 3 wire leads |
| Manufacturer | Delta Electronics |
| Fan Speed | 5000 RPM |
| Fan Type | DC |
| Static Pressure | 0.104 inH2O (2.65 mmH2O) |
| Noise Level | 21.5 dB(A) |
| Air Flow | 5.67 CFM |
| Voltage Rating | 5 VDC |
| Bearing Type | Ball Bearing |
| Weight | 0.031 lb (14.06 g) |
| Category | Axial |
| Current Rating | 0.05 A |
| Operating Voltage | 4.5 ~ 5.5 VDC |
| Material Frame | Plastic |
| Material Blade | Plastic |
| Lifetime @ Temp | 70000 Hrs @ 40°C |
| Product PDF | AFB0405MA-AR00-Delta.pdf |
