Description
9WL0624P4S001 Sanyo Denki San Ace 60W DC 24VDC 60x60x25mm 49.4CFM Ball 53dB(A) 8.16W 11000RPM IP68 4 Wire Leads PWM Control Speed Sensor (Tach) Tubeaxial fan
Specifications
| Part Number | 9WL0624P4S001 |
|---|---|
| Manufacturer | Sanyo Denki |
| Fan Type | DC |
| Series | San Ace 60W |
| Voltage Rating | 24 VDC |
| Dimensions | 60x60x25 mm |
| Air Flow | 49.4 CFM |
| Air Flow (m3) | 1.38m³/min |
| Static Pressure | 1.204 in H2O (299.9 Pa) |
| Bearing Type | Ball Bearing |
| Features | PWM Control, Speed Sensor (Tach) |
| Noise Level | 53 dB(A) |
| Power Rating | 8.16 W |
| Fan Speed | 11000 RPM |
| Termination | 4 Wire Leads |
| IP Rating | IP68 |
| Operating Temperature | -4 ~ 158°F (-20 ~ 70°C) |
| Approval Agency | CSA, TUV, UL |
| Weight | 0.243 lb (110.22 g) |
| Subcategory | Tubeaxial |
| Shipping Weight | 0.25 kg |
| Product PDF | 9WL0624P4S001-Sanyo-Denki.pdf |
