Description
The ebmpapst W3G910-KU25-03 is a 910 mm AxiBlade EC axial fan featuring a high-efficiency GreenTech EC motor (M3G150-IF) with an integrated wall ring. This 3-phase unit operates at a nominal voltage of 400 VAC (380–480 VAC range, 50/60 Hz) with a power input of 2.55 kW and a current draw of 3.9 A at a rated speed of 980 RPM. It delivers a maximum airflow of approximately 23,685 m³/h and is designed for a back pressure of up to 220 Pa. Constructed with a 5-blade PP plastic impeller and a robust galvanized sheet steel housing, it supports RS-485 Modbus RTU communication and 0-10V/PWM control interfaces. With an IP55 protection rating and maintenance-free ball bearings, the W3G910-KU25-03 provides exceptional aerodynamic efficiency for large-scale condensers, heat exchangers, and commercial HVAC refrigeration systems.
Specifications
| Part Number | W3G910-KU25-03 |
|---|---|
| Manufacturer | ebm-papst |
| Fan Speed | 980 RPM |
| Voltage Range | 380~480V |
| Max. back pressure | 220Pa |
| Frequency | 50/60 Hz |
| Fan Type | AC |
| Air Flow (m3) | 20000 m3/h |
| Power Rating | 2550 W |
| Current Rating | 3.9 A |
| Static Pressure Pa | 220 Pa |
| Operating Temperature | -40 ~ 140°F (-40 ~ 60°C) |
| Dimensions | 910 mm |
| Weight | 48kg |
| Bearing Type | Ball Bearing |
| IP Rating | IP55 |
| Phase | 3~ |
| Number of blades | 5 |
| Approval Agency | CE, CSA, EAC, UL |
| Voltage Rating | 400 VAC |
| Subcategory | EC axial fan |
| Shipping Weight | 50 kg |
| Technical Specifications | W3G910-KU25-03-ebmpapst.pdf |
