Description
G1G097-AA05-01 ebmpapst 24VDC 143x137x40mm Ball 16W 2650RPM IP22 4 Wire Leads with Splice Terminals PWM Control, Speed Sensor (Tach) Blower DC Fan
The G1G097-AA05-01 centrifugal fan is a forward-curved single-inlet EC fan with housing (without flange) introduced by ebm-papst. It has a rated voltage of 24VDC (wide voltage range 16-28VDC), speed of 2650rpm, and power of 16W. Made of hot-dip galvanized steel sheet for both housing and impeller, it weighs 0.8kg, features protection class IP22, supports any mounting position, and is equipped with ball bearings and axial cable outlet (PVC AWG22 cable, 4-core crimped terminals). It integrates reverse polarity/locked-rotor protection and soft start functions, supports 0-10VDC/PWM speed regulation and tach output (2 pulses per revolution, 10mA sink current), and operates at -25℃~60℃ (storage at -40℃~80℃). In air performance, max airflow is 90m³/h (0Pa) at 24V, and static pressure reaches 269Pa at 28V/45m³/h. Compliant with EN 60950-1, it suits heat dissipation and ventilation in compact equipment.
Specifications
| Part Number | G1G097-AA05-01 |
|---|---|
| Manufacturer | ebm-papst |
| Series | G1G097 |
| Voltage Rating | 24 VDC |
| Dimensions | 143x137x40 mm |
| Bearing Type | Ball Bearing |
| Fan Type | DC |
| Features | PWM Control, Speed Sensor (Tach) |
| Noise Level | 59 dB(A) |
| Power Rating | 16 W |
| Fan Speed | 2650 RPM |
| Termination | 4 Wire Leads with Splice Terminals |
| IP Rating | IP22 |
| Operating Temperature | -13 ~ 140°F (-25 ~ 60°C) |
| Approval Agency | EAC |
| Subcategory | Blower |
