Description
D3G225-CD03-H1 ebmpapst 230VAC 225mm 1063.1CFM Ball 500W 1100RPM IP55 5 Wire Leads with Ferrules, 5 Wire Leads with Ferrules Blower, Centrifugal Alarm Electronic Commutation (EC) PWM Control Thermal Overload Protector (TOP) AC Fan
Specifications
| Part Number | D3G225-CD03-H1 |
|---|---|
| Static Pressure | 1.770 in H2O (441.0 Pa) |
| Series | D3G225 |
| Fan Type | AC |
| Voltage Rating | 230 VAC |
| Dimensions | 397x327x387 mm |
| Air Flow | 1063.1 CFM |
| Air Flow (m3) | 29.77m³/min |
| Manufacturer | ebm-papst |
| Subcategory | Blower, Centrifugal |
| Bearing Type | Ball Bearing |
| Features | Alarm, Electronic Commutation (EC), PWM Control, Thermal Overload Protector (TOP) |
| Power Rating | 500 W |
| Fan Speed | 1100 RPM |
| Termination | 5 Wire Leads with Ferrules, 5 Wire Leads with Ferrules |
| IP Rating | IP55 |
| Operating Temperature | -13 ~ 122°C (-25 ~ 50°C) |
| Approval Agency | CE, CSA, EAC, UL |
| Shipping Weight | 11 kg |
| Product PDF | D3G225-CD03-H1-ebmpapst.pdf |
