Description
BFB1012EH-A Delta 97.2×94.4x33mm Ball 12VDC 46.00CFM(1.302m3/min) 2.814inchH2O(71.48mmH2O) 64.0dB(A) 29.40W 5300RPM 2wireleads Blower
Specifications
| Part Number | BFB1012EH-A |
|---|---|
| Fan Type | DC |
| Approval Agency | CE, CSA, UL, VDE |
| Operating Temperature | 14 ~ 140°F (-10 ~ 60°C) |
| Features | Locked Rotor Protection |
| Series | BFB |
| Air Flow (m3) | 1.302 m3/min |
| Dimensions | 97.2×94.4×33 mm |
| Termination | 2 wire leads |
| Manufacturer | Delta Electronics |
| Fan Speed | 5300 RPM |
| Power Rating | 29.40 W |
| Noise Level | 64.0 dB(A) |
| Static Pressure | 2.814 inchH2O (71.48 mmH2O) |
| Air Flow | 46 CFM |
| Voltage Rating | 12 VDC |
| Bearing Type | Ball Bearing |
| Weight | 0.397 lb (180.08 g) |
| Category | Blower |
| Current Rating | 2.45 A |
| Operating Voltage | 7 ~ 12.6 VDC |
| Material Frame | Plastic |
| Material Blade | Plastic |
| Lifetime @ Temp | 50000 Hrs @ 40⁰C |
| Shipping Weight | 0.5 kg |
| Product PDF | BFB1012EH-A-Delta.pdf |
