Description
AFB0712HB Delta 70x70x15mm Ball 12VDC 33.20CFM(0.940m3/min) 0.162inchH2O(4.12mmH2O) 34.5dB(A) 2.16W 3800RPM 2wireleads fan
Specifications
| Part Number | AFB0712HB |
|---|---|
| Fan Type | DC |
| Approval Agency | CE, CSA, UL, VDE |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Features | Locked Rotor Protection |
| Series | AFB |
| Air Flow (m3) | 0.940 m3/min |
| Dimensions | 70x70x15 mm |
| Termination | 2 wire leads |
| Manufacturer | Delta Electronics |
| Fan Speed | 3800 RPM |
| Power Rating | 2.16 W |
| Noise Level | 34.5 dB(A) |
| Static Pressure | 0.162 inchH2O (4.12 mmH2O) |
| Air Flow | 33.20 CFM |
| Voltage Rating | 12 VDC |
| Bearing Type | Ball Bearing |
| Weight | 0.104 lb (47.17 g) |
| Category | Axial |
| Current Rating | 0.18 A |
| Operating Voltage | 4 ~ 13.8 VDC |
| Material Frame | Plastic |
| Lifetime @ Temp | 70000 Hrs @ 40⁰C |
| Shipping Weight | 0.25 kg |
| Product PDF | AFB0712HB-Delta.pdf |
