Description
AFB0512LB-A Delta 50x50x15mm Ball 12VDC 11.67CFM(0.330m3/min) 0.119inchH2O(3.03mmH2O) 24.0dB(A) 1.08W 4300RPM 2wire leads fan
Delta AFB0512LB-A is a DC brushless blower with a nominal voltage of 12VDC (operating voltage 5.0-13.8VDC), maximum input current of 0.11A, power of 1.32W, and rotational speed of 4300RPM. It delivers a maximum air flow of 0.330m³/min (minimum 0.297m³/min) and maximum static pressure of 3.031mmH₂O (minimum 2.455mmH₂O), with an average acoustic noise of 24.0dB(A) (maximum 28.0dB(A)). The frame and impeller are made of UL 94V-0 flame-retardant plastic, equipped with double ball bearings, weighing 20g, and rotating clockwise from the nameplate side. It uses UL 1007-F AWG#24 leads (red+ black-), operates at -10°C to 70°C, stores at -40°C to 75°C, and features locked rotor protection (preventing fire within 96h of lock-up) and reverse polarity protection, with a 70,000-hour lifespan at 40°C/15%-65%RH, suitable for low-power and low-noise cooling in small devices.
Specifications
| Part Number | AFB0512LB-A |
|---|---|
| Manufacturer | Delta Electronics |
| Dimensions | 50x50x15 mm |
| Termination | 2 wire leads |
| Approval Agency | CE, CSA, UL, VDE |
| Features | Locked Rotor Protection |
| Series | AFB |
| Air Flow (m3) | 0.330 m3/min |
| Fan Type | DC |
| Fan Speed | 4300 RPM |
| Power Rating | 1.08 W |
| Noise Level | 24.0 dB(A) |
| Static Pressure | 0.119 inchH2O (3.03 mmH2O) |
| Air Flow | 11.67 CFM |
| Voltage Rating | 12 VDC |
| Bearing Type | Ball Bearing |
| Weight | 0.045 lb (20.41 g) |
| Category | Axial |
| Current Rating | 0.09 A |
| Operating Voltage | 5 ~ 13.8 VDC |
| Material Frame | Plastic |
| Material Blade | Plastic |
| Lifetime @ Temp | 70000 Hrs @ 40⁰C |
